SymbolicCurvesFromCADLayers

Inputs

importInstance : ImportInstance
layerNames : string[] (optional)
lineStyleMap : string[] (optional)

Outputs

SymbolicCurve[][] : SymbolicCurve[][]
layerNameKeys[] : string[]


Description

Convert curves from a CAD Link or Import to Revit Family Symbolic Lines using the import instance layer names as filters.

Curves are output in sublists based on their layer name and mapped to the Family’s default Line Style to prevent unwanted CAD Line Styles from entering your project. Alternatively, Line Style names can be input to map each curve sublist to that style during conversion. Layer names can be input to filter and convert only curves on those layers. To convert all layers, leave the layerNames input unconnected. Input layerNames and lineStyleMap are case-sensitive.

The node is optimised to convert-curve types that typically fail when using Dynamo’s Element.Curves node or Revit’s Explode tool for enhanced performance. The node also circumvents the 10,000 element limit set by Revit for greater workflow flexibility.


Features

Convert curves from CAD Links or Imports to Revit Family Symbolic Curves

Curves can be filtered by layer name

Line Style names can be input to map Line Styles to curves from each layer

Optimised to convert curves that normally fail using standard Dynamo nodes or Revit Explode

Circumvents Revit’s 10k merged element limit


User Guide


Download

Download Example Graph
